iDP-3210 User’s Manual
53/67 CITIZEN
0 Paper near end disable (initial value)
1 Paper near end enable
(20) Enabling/Disabling Panel Switch (ESC c 5 n)
Code : [1B]h + [63]h + [35]h + n
* {0 is less than or equal to n is less than or equal to FF} Data is described in Hex code.
Selecting the paper feed switch valid/invalid.
• "n" is valid only in the lowest bit (n0).
• "n" bit means the followings.
n0 Condition
0 Paper feed SW valid.
1 Paper feed SW invalid.
• The initial value of n is "0".
(21) Printing and Feeding the paper by n lines (ESC d n)
Code : [1B]h + [64]h + n
* {0 is less than or equal to n is less than or equal to FF} Data is described in Hex code.
Prints data inside the buffer and feeds paper by n lines.
• Specified line does not remain.
• The beginning of the line is to be considered as the next printing start position.
(22) Generating specified Pulse (ESC p m n1 n2)
Code : [1B]h + [70]h + m + n + n2
* {m = connector pin No. (See table below.)}
{0 is less than or equal to n1 is less than or equal to FF}
{0 is less than or equal to n2 is less than or equal to FF} Data is described in Hex code.
Signals specified by n1, n2 are output to Connector Pin m.
• Bit m (m0) means the followings.
m0 Condition
0 Drawer kick No. 2 pin
1 Drawer kick No. 5 pin
• ON time is considered as n1 x 2ms and OFF time as n2 x 2ms.
• When m is out of the defined range, n1, n2 are discarded, where no signals are output.
• Drive duty of Drawer is shown below:
ON time
ON time + OFF
is less than or equal to 0.2
(Take OFF time as being 4 times or more longer than ON time.)
(23) Selecting Character Code Table (ESC t n)
Code : [1B]h + [74]h + n
* {0 is less than or equal to n is less than or equal to 1} Data is described in Hex code.
Selecting Page n on the character code table:
• "n" means the followings.
n (Hex) Condition
