(24) Transmitting the printer status (ESC v)
Code : [1B]h + [76]h
• Current printer status is transmitted..
Status sent out consists of 1 byte whose content is as in the table below.
• In DTR/DSR control, after receptible state of the host (DSR signal being in SPACE state)
is confirmed, only 1 byte is transmitted. In XON/XOFF control, DSR signal state not being
confirmed, only 1 byte is transmitted.
• In DTR/DSR control, when the host is in unreceptible state(DSR signal being in
MARK state), it waits until receptible state is created.
VALUE
BIT FUNCTION 0 1
0 Not defined
1 Not defined
2 Paper end With paper Without paper
3 Not defined
4 Not used Fixed to 0 -
5 Not defined
6 Not defined
7 Not defined
Remarks. This command is valid only for serial interface model.
(25) Transmitting the status of Peripheral Equipment (ESC u n)
Code : [1B]h + [75]h + n
* {n = 0}
Current status of connector pin No.3 is transmitted.
• "n" means the followings.
n (Hex) Condition
0 Drawer Kick Connector No. 3
• Status transmitted consists of 1 byte whose content is as in the table below.
• Any equipment has not been connected to this connector, Bit 0 of n is always "1".
• In DTR/DSR control, after receptible state of the host (DSR signal being in SPACE state) is
confirmed, only 1 byte is transmitted. Further, in XON/ XOFF control, DSR signal state
not being confirmed, only 1 byte is transmitted.
• In DTR/DSR control, when the host is unreceptible state (DSR signal being in MARK state),
it keeps waiting until receptible state is created.
VALUE
BIT FUNCTION 0 1
0 Level of pin No. 3 “L” “H”
1 Not defined
2 Not defined
3 Not defined
4 Not used Fixed to 0 -
5 Not defined
6 Not defined
7 Not defined
