Removal and Replacement Procedures
Maintenance and Service Guide 5–7
6. Remove the hard drive by following these steps:
a. Turn the notebook upside down, with the rear panel
toward you.
b. Remove the PM2.5×4.0 retaining screw 1 that secures the
hard drive door to the notebook.
c. Remove the PM3.0×3.0 hard drive security screw 2 that
secures the hard drive to the notebook.
d. Lift the hard drive cover 3 and swing it back.
Removing the Hard Drive Screws
Spare Part Number Information
Hard drives (include hard drive frame and connector)
60-GB (5400-rpm)
60-GB (4200-rpm)
40-GB (5400-rpm)
40-GB (4200-rpm)
30-GB (4200-rpm)
344406-001
360291-001
344405-001
359108-001
344404-001
