Removal and Replacement Procedures
Maintenance and Service Guide 5–11
5.5 Mini PCI Communications Board
1. Prepare the notebook for disassembly (Section 5.3).
2. Turn the notebook upside down, with the rear toward you.
3. Loosen the PM2.5×3.5 screw 1 that secures the Mini PCI
compartment cover to the notebook.
4. Lift the left side of the cover 2 up and swing it to the right.
5. Remove the cover.
✎
The Mini PCI compartment cover is included in the
Miscellaneous Plastics Kit, spare part number 353393-001.
Removing the Mini PCI Compartment Cover
Spare Part Number Information
Mini PCI communications cards
802.11a/b/g LAN card
802.11b/g LAN card
325525-001
325526-001
Wireless LAN cards
802.11b (MOW)
802.11b (ROW)
345641-001
345640-001
