Signal Name Ball #
SB_DQ3 AH35
SB_DQ30 AP29
SB_DQ31 AP28
SB_DQ32 AR12
SB_DQ33 AP12
SB_DQ34 AL13
SB_DQ35 AL12
SB_DQ36 AR13
SB_DQ37 AP13
SB_DQ38 AM13
SB_DQ39 AM12
SB_DQ4 AD34
SB_DQ40 AR9
SB_DQ41 AP9
SB_DQ42 AR6
SB_DQ43 AP6
SB_DQ44 AR10
SB_DQ45 AP10
SB_DQ46 AR7
SB_DQ47 AP7
SB_DQ48 AM9
SB_DQ49 AL9
SB_DQ5 AD35
SB_DQ50 AL6
SB_DQ51 AL7
SB_DQ52 AM10
SB_DQ53 AL10
SB_DQ54 AM6
SB_DQ55 AM7
SB_DQ56 AH6
SB_DQ57 AH7
SB_DQ58 AE6
SB_DQ59 AE7
SB_DQ6 AG34
SB_DQ60 AJ6
SB_DQ61 AJ7
continued...
Signal Name Ball #
SB_DQ62 AF6
SB_DQ63 AF7
SB_DQ7 AH34
SB_DQ8 AL34
SB_DQ9 AL35
SB_DQS0 AF35
SB_DQS1 AL33
SB_DQS2 AP33
SB_DQS3 AN28
SB_DQS4 AN12
SB_DQS5 AP8
SB_DQS6 AL8
SB_DQS7 AG7
SB_DQS8 AN25
SB_DQSN0 AF34
SB_DQSN1 AK33
SB_DQSN2 AN33
SB_DQSN3 AN29
SB_DQSN4 AN13
SB_DQSN5 AR8
SB_DQSN6 AM8
SB_DQSN7 AG6
SB_DQSN8 AN26
SB_ECC_CB0 AM26
SB_ECC_CB1 AM25
SB_ECC_CB2 AP25
SB_ECC_CB3 AP26
SB_ECC_CB4 AL26
SB_ECC_CB5 AL25
SB_ECC_CB6 AR26
SB_ECC_CB7 AR25
SB_MA0 AL19
SB_MA1 AK23
SB_MA10 AP18
SB_MA11 AY25
SB_MA12 AV26
continued...
Signal Name Ball #
SB_MA13 AR15
SB_MA14 AV27
SB_MA15 AY28
SB_MA2 AM22
SB_MA3 AM23
SB_MA4 AP23
SB_MA5 AL23
SB_MA6 AY24
SB_MA7 AV25
SB_MA8 AU26
SB_MA9 AW25
SB_ODT0 AM17
SB_ODT1 AL16
SB_ODT2 AM16
SB_ODT3 AK15
SB_RAS# AM18
SB_WE# AK16
SKTOCC# D38
SM_DRAMPWRO
K
AK21
SM_DRAMRST# AK22
SM_RCOMP0 R1
SM_RCOMP1 P1
SM_RCOMP2 R2
SM_VREF AB38
SSC_DPLL_REF_
CLKN
U5
SSC_DPLL_REF_
CLKP
U6
TCK D39
TDI F38
TDO F39
TESTLO_N5 N5
TESTLO_P6 P6
THERMTRIP# F37
TMS E39
TRST# E37
continued...
Processor—Processor Ball and Signal Information
Desktop 4th Generation Intel
®
Core
™
Processor Family, Desktop Intel
®
Pentium
®
Processor Family, and Desktop Intel
®
Celeron
®
Processor Family
Datasheet – Volume 1 of 2 December 2013
114 Order No.: 328897-004
