[ Connectors & Controls ]
9
Controls and Connectors
Figure 1 and the table following identify and describe the controls, connectors, and
various mounting connections of the dock.
Locking
Screw Hole
Radio Release Button
Radio Adapter
Mounting Hole
Dock
Mounting Hole
Antenna
Connector
Sirius Universal Docking Connector
Radio Adapter
Alignment Holes
SiriusConnect
Interface Connecto
r
Pedestal Mount
Mounting Holes
Bottom
View
Front
View
Back
View
Figure 1Figure 1
