– 125 –
KP-43T70C/53SV70C/61SV70C
RM-Y906 RM-Y906 RM-Y906
MISCELLANEOUS
*****************
! 1-223-925-11 RESISTOR ASSY (HIGH-VOLTAGE)
(FOCUS PACK)
! 1-451-469-21 COIL ASSY, VM (61SV70C)
! 1-451-496-11 DEFLECTION YOKE
! 1-452-790-21 NECK ASSY (43T70C/53SV70C)
! 1-452-909-31 MAGNET ASSY, 4 POLE
(43T70C/53SV70C)
1-529-396-11 SPEAKER (10cm) (43T70C)
1-529-401-11 SPEAKER (13cm) (53SV70C)
1-529-402-11 SPEAKER (16cm) (61SV70C)
1-529-403-11 SPEAKER (6.6cm)
1-556-945-21 CABLE, P-P
* 1-557-056-31 CABLE, P-P
! 1-769-796-11 CORD, POWER (WITH CONNECTOR)
! 8-598-414-20 CHANGER, ANTENNA
! 8-598-955-30 BLOCK ASSY, HIGH VOLTAGE
! 8-733-570-15 CRT 07MXC2(G)(HEATER)
! 8-733-571-15 CRT 07MXC2(R)(HEATER) (43T70C)
! 8-733-572-15 CRT 07MXC3(R)(HEATER) (53SV70C)
! 8-733-573-15 CRT 07MXC4(R)(HEATER) (61SV70C)
! 8-733-574-15 CRT 07MAC2(B)(HEATER) (43T70C)
! 8-733-575-15 CRT 07MAC3(B)(HEATER) (53SV70C)
! 8-733-576-15 CRT 07MAC4(B)(HEATER) (61SV70C)
**************************************************************
ACCESSORIES AND PACKING MATERIALS
****************************************
3-867-647-21 MANUAL, INSTRUCTION
* 4-041-423-01 SHEET, PROTECTION (43T70C)
* 4-041-426-01 BAG, PROTECTION (53SV70C)
* 4-041-428-01 BAG, POLYETHYLENE (61SV70C)
* 4-042-463-01 SHEET, PROTECTION (53SV70C)
* 4-042-463-01 SHEET, PROTECTION (61SV70C)
* 4-049-155-01 BAG, PROTECTION (43T70C)
* 4-069-537-01 ASSY, CUSHION (UPPER) (43T70C)
* 4-069-538-01 ASSY, CUSHION (LOWER) (43T70C)
* 4-069-543-01 INDIVIDUAL CARTON (43T70C)
REF. NO. PART NO. DESCRIPTION REMARK
–––––––– ––––––––– ––––––––––––– –––––––––
REF. NO. PART NO. DESCRIPTION REMARK
–––––––– ––––––––– ––––––––––––– –––––––––
The components identified by
shading and mark
! are criti-
cal for safety.
Replace only with part number
specified.
* 4-069-545-01 TRAY (43T70C)
* 4-069-573-01 INDIVIDUAL CARTON (53SV70C)
* 4-069-574-01 BOARD, BOTTOM (53SV70C)
* 4-069-575-01 TRAY (53SV70C)
* 4-069-576-01 CUSHION (UPPER) (ASSY) (53SV70C)
* 4-069-577-01 CUSHION (LOWER) (ASSY) (53SV70C)
* 4-069-582-01 INDIVIDUAL CARTON (61SV70C)
* 4-069-583-01 BOARD, BOTTOM (61SV70C)
* 4-069-584-01 TRAY (61SV70C)
* 4-069-585-01 CUSHION (UPPER) (ASSY) (61SV70C)
* 4-069-586-01 CUSHION (LOWER) (ASSY) (61SV70C)
REMOTE COMMANDER
**********************
1-418-469-11 REMOTE COMMANDER (RM-Y906)
4-978-977-01 COVER, BATTERY (FOR RM-Y906)
