4ReplacementProcedures
SatelliteL500DMaintenanceManual 4-v
Figures
Figure4.1 RemovingtheBatteryPack............................................................................4-8
Figure4.2 RemovingtheHDDdoor.............................................................................4-10
Figure4.3 RemovingtheHDDplate.............................................................................4-11
Figure4.4 RemovingtheRAMdoor.............................................................................4-13
Figure4.5 RemovingtheRAMfromthelaptop............................................................4-14
Figure4.6 RemovingtheODDBaymodule.................................................................4-16
Figure4.7 RemovingthebracketfromtheODDdrive.................................................4-17
Figure4.8 Removingthekeyboardcover......................................................................4-19
Figure4.9 Removingscrewsfromthekeyboard...........................................................4-20
Figure4.10 Removingthekeyboard................................................................................4-21
Figure4.11 RemovingtheWLANcard...........................................................................4-22
Figure4.12 Removingthescrewsfromthebottomofthelaptop...................................4-23
Figure4.13 Removingsixscrewsfromunderthekeyboard...........................................4-24
Figure4.14 Detachingcablesfromunderthekeyboard..................................................4-25
Figure4.15 Removingthepowerboard..........................................................................4-26
Figure4.16 Removingthescrewsfromthetouchpadbuttonboard...............................4-27
Figure4.17 Removingthetouchpadbracket..................................................................4-28
Figure4.18 Removingthethermalfanfromthelogiclowerassembly...........................4-29
Figure4.19 Removingthemotherboardfromlogiclowerassembly..............................4-30
Figure4.20 RemovingtheDCINconnectorandcable...................................................4-31
Figure4.21 Pickingupthemotherboard.........................................................................4-31
Figure4.22 Aligningthemotherboardconnectors..........................................................4-32
Figure4.23 InstallingtheDCINconnector.....................................................................4-33
Figure4.24 RemovingtheThermalModule...................................................................4-35
Figure4.25 RemovingtheVGABoard...........................................................................4-36
Figure4.26 ReapplyShinetsu7726greaseonthethermalmoduleand
removeanyreleasepapers
............................................................................4-37
Figure4.27 RemovingtheCPU.......................................................................................4-38
Figure4.28 Removingthemodemcard..........................................................................4-40
Figure4.29 Removingthespeakers.................................................................................4-41
Figure4.30 Removingthedisplayassembly...................................................................4-43
