LiverpoolL500D/ProL500DSeriesMaintenanceManual C-3
C.6 JHDD
TableC-6HDDI/Fpinassignments(22-pin)
PinNo. Signalname I/O PinNo. SignalName I/O
1 GND - 2 SATA_TXP1 O
3 SATA_TXN1 O 4 GND -
5 SATA_IRX_DT
X_N1
O 6 SATA_IRX_DT
X_P1
O
7 GND - 8 +3VS -
9 +3VS - 10 +3VS -
11 GND - 12 GND -
13 GND - 14 +5VS -
15 +5VS - 16 +5VS -
17 GND - 18 NC -
19 GND - 20 NC -
21 NC 22 NC -
C.7 JODD
TableC-7SATAODDI/Fpinassignments(14-pin)
PinNo. Signalname I/O PinNo. SignalName I/O
1 GND - 2 SATA_STX_D
RX_P3_16
O
3 SATA_STX_D
RX_N3_16
O 4 GND -
5 SATA_RXN3_
C_16
O 6 SATA_RXP3_
C_16
O
7 GND - 8 NC -
9 +5VS - 10 +5VS -
11 NC - 12 GND -
13 GND - 14 GND -
