User’s Manual 2-5
A500/A500D series
Right side
The following figure shows the computer’s right side.
Figure 2-3 The right side of the computer
*a. Optical disc drive (tray)
b. Universal Serial Bus (USB 2.0) port
c. DC IN 19V jack
d. Security lock slot
*e. TV Tuner jack
*f. Optical Disc drive (slot)
*Depending on the model you purchased.
a b c d
e
f
Optical disc drive
(tray)
Some computers are configured with a tray
version of the DVD Super Multi drive. The
full-size drive provides high-performance
execution of CD/DVD-ROM-based programs.
Universal Serial Bus
(USB 2.0) port
Two Universal Serial Bus ports, which comply
with the USB 2.0 standard, are provided on the
right side of the computer.
