show cos port-config

D-Series CLI Reference 9-23

groups(1through7)canbeconfigured.Currently,onlyoneporttype(type0)issupported.This

porttypesupports100limiters.

Additionalportgroupsmaybecreatedforflexibility.Portsassignedtoanewportgroupmustbe

mutuallyexclusivefromtheotherportgroupentries—portsareautomaticallyremovedfrom

the

defaultportgroup—andmustbecomprisedofthesameporttypeasdefinedbytheportgroup.

Thecreationofadditionalportgroupscouldbeusedtocombinesimilarportsbytheirfunctionfor

flexibility.Forinstance,portsassociatedtouserscanbeaddedtoaportgroupcalled“Users”

and

portsassociatedtouplinkportscanbeaddedtoaportgroupcalled“Uplink.”Usingtheseport

groups,asingleclassofservicecanassigndifferentratelimitstoeachportgroup.“User”ports

canbeassignedoneratelimit,while“Uplink”portscanbeassignedanother.DFEsupportsa



maximumof8portgroupsperCoSfunction(IRL).

Thecommandshowcosport‐configdisplayseachIRLportgroupconfiguredbygroupandtype,

withthegroupnameandassociated(assigned)ports.Thecommandshowcosport‐typedisplays

theavailableinboundratelimitingresourcesfortheporttype.

Example

Thisexampleconfigurestwoportgroups,oneforuserportsandoneforuplinkportsandassign

portstothegroups.Portgroup1.0willrepresentuserports,group2.0willrepresentuplinkports.

D2(su)->set cos port-config irl 1.0 name Users ports ge.1.1-46

D2(su)->set cos port-config irl 2.0 name Uplink ports ge.1.47-48

show cos port-config

Usethiscommandtoshowinboundratelimitinggroupsandtheassignedports.

Syntax

show cos port-config [irl group-type-index]

Parameters

Defaults

Theshowcosport‐configcommandbyitselfwillshowallPortGroups.

Mode

Switchcommand,read‐only.

Example

Thisexampleshowsallinboundratelimitingportgroups.Notethatportsge.1.1throughge.1.48

wereremovedfromthedefaultportgroup0.0whentheywereaddedtoportgroups1.0and2.0.

D2(su)->show cos port-config

irl (Optional)Specifiesthatinboundratelimitingconfigurationinformation

shouldbedisplayed.

group‐type‐index (Optional)Showassignedportsforaspecificportgroup.Validentriesare

intheformofgroup#.port‐type.

Validvaluesforgroup#canrangefrom0to7.Validvaluesforport‐type

canrangefrom0

to1,althoughonlyporttype0iscurrentlysupported.

Forexample,portgroup3wouldbespecifiedas3.0.
