Services Firewall configuration
Providing access to custom services
Add a custom service if you need to create a policy for a service that is not in the
predefined service list.
1 Go to Firewall > Service > Custom.
2 Select New.
3 Enter a Name for the service. This name appears in the service list used when you
add a policy.
The name can contain numbers (0-9), uppercase and lowercase letters (A-Z, a-z), and
the special characters - and _. Other special characters and spaces are not allowed.
4 Select the Protocol (either TCP or UDP) used by the service.
RAUDIO For streaming real audio multimedia traffic. udp 7070
RLOGIN Rlogin service for remotely logging into a
server.
tcp 513
RIP Routing Information Protocol is a common
distance vector routing protocol.
udp 520
SMTP For sending mail between email servers on the
Internet.
tcp 25
SNMP Simple Network Management Protocol is a set
of protocols for managing complex networks
tcp 161-162
udp 161-162
SSH SSH service for secure connections to
computers for remote management.
tcp 22
udp 22
SYSLOG Syslog service for remote logging. udp 514
TALK A protocol supporting conversations between
two or more users.
udp 517-518
TCP All TCP ports. tcp 0-65535
TELNET Telnet service for connecting to a remote
computer to run commands.
tcp 23
TFTP Trivial file transfer protocol, a simple file
transfer protocol similar to FTP but with no
security features.
udp 69
UDP All UDP ports. udp 0-65535
UUCP Unix to Unix copy utility, a simple file copying
protocol.
udp 540
VDOLIVE For VDO Live streaming multimedia traffic. tcp 7000-7010
WAIS Wide Area Information Server. An Internet
search protocol.
tcp 210
WINFRAME For WinFrame communications between
computers running Windows NT.
tcp 1494
X-WINDOWS For remote communications between an
X-Window server and X-Window clients.
tcp 6000-6063
Table 6: FortiGate predefined services (Continued)
Service name Description Protocol Port
