IP/MAC binding Firewall configuration
You can enter the static IP addresses and corresponding MAC addresses of trusted
computers in the Static IP/MAC table.
IP/MAC binding can be enabled for packets connecting to the firewall or passing
through the firewall.
This section describes:
• Configuring IP/MAC binding for packets going through the firewall
• Configuring IP/MAC binding for packets going to the firewall
• Adding IP/MAC addresses
• Viewing the dynamic IP/MAC list
• Enabling IP/MAC binding
Configuring IP/MAC binding for packets going through the firewall
Use the following procedure to use IP/MAC binding to filter packets that would
normally be allowed through the firewall by a firewall policy.
1 Go to Firewall > IP/MAC Binding > Setting.
2 Select Enable IP/MAC binding going through the firewall.
3 Go to Firewall > IP/MAC Binding > Static IP/MAC.
4 Select New to add IP/MAC binding pairs to the IP/MAC binding list.
All packets that would normally be allowed through the firewall by a firewall policy are
first compared with the entries in the IP/MAC binding list. If a match is found, then the
firewall attempts to match the packet with a policy.
For example, if the IP/MAC pair IP 1.1.1.1 and 12:34:56:78:90:ab:cd is added to the
IP/MAC binding list:
• A packet with IP address 1.1.1.1 and MAC address 12:34:56:78:90:ab:cd is
allowed to go on to be matched with a firewall policy.
• A packet with IP 1.1.1.1 but with a different MAC address is dropped immediately
to prevent IP spoofing.
• A packet with a different IP address but with a MAC address of
12:34:56:78:90:ab:cd is dropped immediately to prevent IP spoofing.
• A packet with both the IP address and MAC address not defined in the IP/MAC
binding table:
• is allowed to go on to be matched with a firewall policy if IP/MAC binding is set
to Allow traffic,
• is blocked if IP/MAC binding is set to Block traffic.
Note: If you enable IP/MAC binding and change the IP address of a computer with an IP or
MAC address in the IP/MAC list, you must also change the entry in the IP/MAC list or the
computer will not have access to or through the FortiGate unit. You must also add the IP/MAC
address pair of any new computer that you add to your network or this computer will not have
access to or through the FortiGate unit.
