ADF left cover
1. Open the ADF top cover.
1
2
Figure 5-45 Removing the ADF left cover (1 of 3)
2. Remove one screw (callout 1) and release the arm (callout 2).
2
1
Figure 5-46 Removing the ADF left cover (2 of 3)
ENWW External components and covers 69
