Chapter 4 55
Front/Rear Panel
Rear Panel
Line Module
The line module contains the power cable receptacle. See “Step 4. Satisfy Electrical
and Environmental Requirements” for power supply requirements.
Power Cables The line power cable is supplied in one of several configurations, depending on the
destination of the original shipment.
Each instrument is equipped with a three-wire power cable. When connected to an
appropriate ac power receptacle, this cable grounds the instrument chassis. The type
of power cable shipped with each instrument depends on the country of destination.
See Figure 4-3 for the part numbers of these power cables. Cables are available in
different lengths. Check with your nearest Agilent service center for descriptions
and part numbers of cables other than those described in Figure 4-3.
WARNING This is a Safety Class I product (provided with a protective earthing ground
incorporated in the power cord). The mains plug shall only be inserted in a
socket outlet provided with a protective earth contact. Any interruption of the
protective conductor, inside or outside the instrument, is likely to make the
instrument dangerous. Intentional interruption is prohibited.
