Asus A7V266-MX Computer Hardware User Manual



ASUS A7V266-MX motherboard user guide
2-25
2.6.1 Power Up Control
PS2KB Wakeup Select [Hot Key]
This parameter allows you to use specific keys on the keyboard to turn on the system.
This feature requires an ATX power supply that provides at least 1A on the +5VSB lead.
Configuration options: [Disabled] [Ctrl+F1]...[Ctrl+F12] [Power] [Wake] [Any Key]
PS2KB Wakeup from S3/S4/S5 [Disabled]
When set to [Enabled], this parameter allows you to use the PS/2 keyboard to turn
on the system. Configuration options: [Disabled] [Enabled]
PS2MS Wakeup from S3/S4/S5 [Disabled]
When set to [Enabled], this parameter allows you to use the PS/2 mouse to turn on
the system. This requires an ATX power supply that provides at least 1A on the
+5VSB lead. Configuration options: [Disabled] [Enabled]
USB Resume from S3 [Disabled]
Configuration options: [Disabled] [Enabled]
Power On by PCI Card [Disabled]
When set to [Enabled], this parameter allows tyou to turn on the system through the
PCI LAN or modem card. This feature requires an ATX power supply that provides at
least 1A on the +5VSB lead. Configuration options: [Disabled] [Enabled]
Modem Ring Resume [Disabled]
This allows either settings of [Enabled] or [Disabled] for powering up the computer
when the external modem receives a call while the computer is in Soft-off mode.
Configuration options: [Disabled] [Enabled]
RTC Alarm Resume [Disabled]
Allows you to enable or disable RTC to generate a wake event. When this item is
enabled, the Date and Resume Time fields are activated for manual setup.
Configuration options: [Disabled] [Enabled]
PS2KB Wakeup Select [Hot Key]
PS2KB Wakeup from S3/S4/S5 [Disabled]
PS2MS Wakeup from S3/S4/S5 [Disabled]
USB Resume from S3 [Disabled]
Power On by PCI Card [Disabled]
Modem Ring Resume [Disabled]
RTC Alarm Resume [Disabled]
Date (of Month) 0
Resume Time 0 : 0 : 0
Power Up Control
Allows keyboard keys
to turn on the system.
