5. Physical installation
5.1 Installation of the support structure
What has to be done?
The complete support structure has to be assembled and installed in its final position.
Screen supporting/securing structures vary from system to system. Consult Barco for advise on professional
rigging organizations.
SF-10V mounting plates.
Barco provides mounting plates for the SF-10V tiles which can be used to clamping the tiles to the support structure.
A
B
Image 5-1
A Middle mounting plate.
B Top / Bottom mounting plate.
32 R59770542 SF-10V DISPLAY 10/02/2012
