40 4025083 Rev A
How Do I Configure My DOCSIS Residential Gateway?
Section
Field Description
VPN Tunnel
Select Tunnel Entry
Allows you to display a list of created VPN tunnels
Create Button
Click this button to create a new tunnel entry
Delete Button
Click this button to delete all settings for the selected tunnel
Summary Button
Click this button to display the settings and status of all enabled
tunnels
IPSec VPN Tunnel
Allows you to enable or disable Internet Security Protocol for the
VPN tunnel
Tunnel Name
Enter the name for this tunnel
Local Secure Group
Select the local LAN user(s) that can use this VPN tunnel. This may
be a single IP address or sub-network. Note that the Local Secure
Group must match the remote gateway's Remote Secure Group.
IP
Enter the IP address of the local network
Mask
If the Subnet option is selected, enter the mask to determine the IP
address on the local network
Remote Secure
Group
Select the remote LAN user(s) behind the remote gateway who can
use this VPN tunnel. This may be a single IP address, a sub-network,
or any addresses. If "Any" is set, the Gateway acts as responder and
accepts requests from any remote user. Note that the Remote Secure
Group must match the remote gateway's Local Secure Group.
IP
Enter the IP address of the remote network
Mask
If the Subnet option is selected, enter the mask to determine the IP
addresses on the remote network
