74 4025083 Rev A
Monitor Gateway Status
Section
Field Description
Signal to Noise Ratio
Displays the signal to noise ratio in dBmv.
Upstream Channels
Channel ID
Displays the channel ID.
Upstream Frequency
Displays the upstream frequency in Hz.
Modulation
Displays one of the following modulation types currently in
use:
QPSK, 8 QAM, 16 QAM, 32 QAM, 64 QAM, or 128 QAM
Bit Rate
Displays the Bit Rate in kBits/sec.
Power Level
Displays the upstream power level in dBmv.
Status > DOCSIS Status
Important: This page is only visible until the gateway goes online. After the gateway
is online and registered on the network, this page is no longer visible.
The DOCSIS Status page displays a detailed status report of the DOCSIS status,
Ethernet link status for each interface, QoS status, and configuration parameters for
the residential gateway.
