Citizen CBM1000II Printer User Manual



— 12 —
ENGLISH
4
25
4422
(1) Thermal Paper roll
Maximum print area 72
Paper width 80 +0/-1
Maximum print area 54
Paper width 58
2.4 Print Paper Specifications and Print Position
Printing surface
ø83 or less
(Recommended papers)
TF50KS-E2C from Nippon Paper
KP50 from Shin-Ohji Paper
F230AA or HP220A from Mitsubishi
Paper or equivalent
(2) Thermal label sheet (label gap detection) * Only L-Spec.
Base sheet width: 58 +0/-1
Maximum print area 72
Maximum print area 50
Minimum label gap
Unit: mm
ø12
60~80 µm
ø18
ø25~28
65~85 µm
Max. label width: 54
Max. label width: 76
Base sheet width: 80 +0/-1
Minimum label length
Approx. 2Approx. 2
ø83 or less
Printing surface
60 µm or less
(Recommended papers)
KPT86S/G63BC P22 from Ohji Tac.
or equivalent
CAUTION
A roll paper not complying with the specifications may cause some departure in print tone.
Adjust print tone with the DIP switch (see “Setting DIP Switches”).
Do not paste paper end to the core as it may cause coloration or faint letters if printed
documents are exposed to a particular chemical or oil afterwards.
Rubbing the document surface with your nail or metallic device may cause coloration.
Coloration occurs at a temperature of around 70°C or above. Keep documents away from
heat, moisture, or light.
Unit: mm
