6-2
6.1 Basic Specifications
Item Description
Printing • Direct-thermal or thermal-transfer
• 203 dpi (8 dots/mm) print head
(Main scanning line density: 8 dots/mm)
(Sub-scanning line density: 8 lines/mm)
• Max. printing width: 4.1 in (104 mm)
• Max. paper width: 4.65 in (118 mm)
• Max. printing length: 32 in (812 mm)
Printing speed • 2–4 inches/second in one-inch units
Print mode • Batch mode: Normal printing (single or multi sheets)
• Peeling mode: Label peeling off the liner after printing
• Cut mode: Cutting and printing by the specified number of
sheets (label feeding back enabled)
• Tear-off mode: Paper feeding back to the printing start position
after cutting
Bar code generator One-dimensional bar code:
•
Code 3 of 9 • UPC-A
• UPC-E • Interleaved 2 of 5
•
ITF14 • ITF16
•
Telepen • Code 128
•
EAN-13 (JAN-13) • Codabar (NW-7)
• HIBC (Modulus 43-used code 3 of 5)
•
EAN-8 (JAN-8) • Int 2 of 5 (Modulus 10-used
Interleaved 2 of 5)
•
Plessey • CASE CODE
•
Code 93 • UPC2DIG ADD
• UPC5DIG ADD
Two-dimensional bar code:
•
UPS Maxi Code • PDF-417
•
QR Code
