Chapter 4 Media (Paper) and Ribbon
−
23
−
10. Close the right side cover and the front cover.
Loading the paper is now completed.
CAUTION
When the inward-wound roll of paper is used, first put the roll of paper onto the paper roll shaft
so that it can be wound clockwise as shown blow, then pull the end of the roll of paper through
the printer as before.
CAUTION
The maximum outer diameter of the inward-wound roll of paper is 250 mm (9.84 in).
The maximum outer diameter of the outward-wound roll of paper is 203 mm (8 in).
Inward-wound
