PPU-231 User’s Manual
18
CITIZEN
4.4 How to Remove Remaining Paper Roll
1. Raise the head-up lever of the printer/presenter unit.
2. Gently pull out the paper from the printer/presenter unit.
If the paper roll is still remaining, cut it just before the
paper insertion slot before pulling it out.
CAUTION:
1) Never take out paper with the head-up lever lowered, because it could damage the printing head.
2) The printer mechanism may be very hot just after printing, so be duly careful.
Head-up Lever
Head-up Lever
Paper Roller
(Printer side)
