2.2 Basic Specifications
Model
Item
iDP-3550 iDP-3551
Printer mechanism Character type: DP654 series/Graphic type: DP657series (CITIZEN)
Print method Serial dot impact method (Bidirectional print), 2-pass graphic (Unidirectional print)
Print width Character type: 63.6 mm/Graphic type: 58.7 mm
Print head 9 pins
Print speed Character type: Approx. 3.6 lines/second/Graphic type: Approx. 3 lines/second
Print columns 40 columns
Character size
Character type: 1.36 mm(W) × 2.4 mm(H) (7 dots)
1.36 mm(W) × 3.1 mm(H) (9 dots)
Graphic type: 1.36 mm(W) × 2.4 mm(H) (7 dots)
1.36 mm(W) × 3.1 mm(H) (9 dots)
Character types Alphanumeric, Katakana, International characters, Code page 850, 860, 863, 865,
852, 866, 857, Windows code
Line spacing Character type: 4.23 mm (1/6 inch)/Graphic type: 2.82mm (1/9 inch)
Paper
Ordinary pape r and non- carbon paper: 76 +/- 0.5 mm(W) × φ83 mm(OD);
Ink ribbon Special purpose ribbon cartridge red/black or single color (Black or Purple)
Interface Serial(RS-232C), Parallel(CENTRONICS compliant)
Command system
CBM mode, STAR mode, ESC/POS mode
The user can select the mode with the DIP switch and preset jumpers.
Print function On-line, self-test, and hex. dump print function
Provided by operating the power, LF, and SEL switches.
Input buffer 6 KB or 256 bytes (Selectable with the DIP switch)
Buff er ba ckup func t ion Within 24 hours (After 10 minutes or more of printer operation)
Drawer function 2-drawer, 1-drawer switch
Auto loading function Automatically feeds the paper by several lines when it is inserted.
Paper end detection Stops printing when the paper has run out.
Paper ne ar end detection
Stops printing when the paper is running out.(Settable with a command)
Auto cutter None AC-134-E (Capable of partial and full
cut)
Winder Special purpose winder AW-3-E (Option) that will be placed separately.
Supply voltage 120 V AC +/- 10 %, 50/60 Hz
230 V AC +/- 10 %, 50/60 Hz
Power consumption Not printing: Approx. 10 W, Printing: Approx. 30 W
Weight Approx. 2.8 kg Approx. 3 kg
Outer dimensions
160 (W) × 212 (D) × 194 (H) mm 160 (W) × 212 (D) × 173 (H) mm
Ope rating tem perat ure and
hum idity
0 to 40°C, 35 to 85 % RH (No dew condensation)
Storage temperature and
humidity
-20 to 60 °C, 10 to 90 % RH (No dew condensation)
EMI standard U.S.A.: FCC Class-A
Europe: EN55022 Class-B CE Marking
Safety standard U.S.A., Canada: UL, c-UL Europe: TUV, GS
