5.2 DIP Switches Setting
1) DIP Switch 1
No. Function ON OFF
Upon Shipment from Factory
DSW1-1 Auto cutter Yes No ON *1
DSW1-2
International characters
ON *2
DSW1-3
″
ON *2
DSW1-4
″
See the Table below
ON *2
DSW1-5 CBM command
CBM2 mode
(iDP-3530
system)
CBM1 mode
(iDP-3540
system)
OFF*4
DSW1-6 CR mode See the Table below OFF
DSW1-7 Mechanism type Graphic Character OFF
DSW1-8 Buffer size 6K bytes 256 bytes ON
DSW1-9 Operation mode OFF *3
DSW1-10
″
See the table below
OFF *3
*1, *3 : Depends on the type.
*2 : Depends on the destination.
*4 : Effective only when CBM mode is selected with DSW1-9 and -10. For details see “CBM
Mode” in “PRINT CONTROL FUNCTIONS.
International Character Selection Character Code Selection
No.
Country
DSW1-2 DSW1-3 DSW1-4
ESC/POS
mode
CBM mode Star mode
U.S.A. ON ON ON Code 437
CBM
(International)
Star
(International)
France OFF ON ON Code 850 Code 850 Code 850
Germany ON OFF ON
″ ″ ″
U.K. OFF OFF ON
″ ″ ″
Denmark ON ON OFF
″ ″ ″
Sweden OFF ON OFF
″ ″ ″
Italy ON OFF OFF
″ ″ ″
Japan OFF OFF OFF Katakana
CBM
(Japanese)
Star
(Japanese)
See the “International Character Codes Table and Character Codes Table”.
CR mode(DSW1-6) Operation Mode DSW1-9 DSW1-10
Mode OFF ON CBM OFF OFF
CBM CR+LF CR ESC/POS ON OFF
STAR CR+LF Ignored STAR OFF ON
ESC/POS CR+LF CR STAR Auto cut ON ON
