2.3 Paper Specifications
2.3.1 Recommended Paper
•Type : Normal paper and non-carbon paper
•Paper width : 76 +/- 0.5 mm
•Paper thickness : Single-sheet paper --- 45 to 55 kg/1,000 sheets/1,091 × 788 mm
Copying paper --- Non-carbon paper or 1 original + 1 copy
34 kg for each paper
Total thickness 0.2 mm or less
•Roll diameter : φ83 mm or less (φ80 mm or less for the copying paper)
•Core : φ12 mm (Inner Diameter), φ18 mm (Outer Diameter)
2.3.2 Printing Position
2.3.3 Cutter Layout
iDP-3550 tear bar position : Approx. 28 mm
iDP-3551 auto cutter cutting position : Approx. 19 mm
76 mm (3 Inches)
DP-654: Approx. 6.2 mm
DP-657: Approx. 8.65 mm
DP-654: Approx. 6.2 mm
DP-657: Approx. 8.65 mm
DP-654: Approx. 6.3.6 mm
DP-657: Approx. 58.7 mm
Cutting position
iDP-3550 : Approx. 28 mm
iDP-3551 : Approx. 19 mm
Center of the first printing
line
