9. PARALLEL INTERFACE
9.1 Specifications
•Data input system : 8-bit parallel system (DATA1 to DATA8)
•Control signals : ACK, BUSY, STB, FAULT, SELECT, RESET, COMPULSION
•Applicable connectors : Printer side --- 57LE-40360 (Anphenol), or equivalent
Cable side --- 57-30360 (Anphenol), or equivalent
9.2 Connector's Pin Configuration
Mode
No.
CBM STAR ESC/POS
Mode
No.
CBM STAR ESC/POS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
STB
DATA 1
DATA 2
DATA 3
DATA 4
DATA 5
DATA 6
DATA 7
DATA 8
ACK
BUSY
PE(HI-LEVEL)
SELECT
GND
GND
GND
FRAME GND
Vcc
←
←
←
←
←
←
←
←
←
←
←
←
←
←
NC
NC
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
NC
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
TWISTED PAIR GND
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
↑
RESET
FAULT
NC
COMPULSION
NC
Vcc
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
←
GND
←
←
Vcc
NC
