Adding and Replacing Parts 119
NOTICE: To help prevent damage to the system board, you must remove the battery from the battery bay before
you begin working inside the computer.
1
Follow the procedures in "Before You Begin" on page 109.
2
Remove the hinge cover.:
a
Open the display all the way (180 degrees) so that it lies flat against your work surface.
NOTICE: To avoid damage to the hinge cover, do not lift the cover on both sides simultaneously.
b
Insert a scribe into the indent to lift the hinge cover on the right side.
c
Ease the hinge cover up, moving from right to left, and remove it.
NOTE: When replacing the hinge cover, first insert the left edge and then press from left to right until the cover
snaps into place.
Keyboard
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching an unpainted metal surface (such as a connector on the back of the computer).
1 hinge cover 2 scribe
1
2
