Installation Drawings
51
Figure 38 Installation drawing, seismic floor stand 400-600A
A
2 PLACES
DETAIL A
REAR UPPER STS2 BRACKET
REAR LOWER STS2 BRACKET
UPPER REAR BRACKET TABS TO
SLIDE INTO LOWER REAR
BRACKET SLOTS
(2 PLACES)
CAP SCREW M10-1.5X30MM SPLIT
LOCK WASHER M10 FLAT WASHER M10
(2 PLACES)
CAP SCREW M12-1.75X40MM
SPLIT LOCK WASHER M12
FLAT WASHER M12
LOWER FRONT BRACKET
NOTE:
SEE DWGS PS216000, PS216001, AND PS216003
FOR DETAILS.
FIG. 2
REAR RIGHT ISOMETRIC VIEW
FIG. 3
RIGHT SIDE VIEW
FIG. 1
FRONT LEFT ISOMETRIC VIEW
PS216002 Rev. 0
