80
Group 3:
User
Settings
1
SCR1 Fast Undervoltage
Setpoint
Integer In % of nominal below nominal
2
SCR1 Slow Undervoltage
Setpoint
Integer In % of nominal below nominal
3
SCR1 Slow Undervoltage
Detect Delay
Integer In number of lines cycles
4
SCR1 Overvoltage
Setpoint
Integer In % of nominal above nominal
5
SCR1 Overvoltage Detect
Delay
Integer In 1/4 lines cycles
6
SCR1 I peak Transfer
Setpoint
Integer x 10
7
SCR2 Fast Undervoltage
Setpoint
Integer In % of nominal below nominal
8
SCR2 Slow Undervoltage
Setpoint
Integer In % of nominal below nominal
9
SCR2 Slow Undervoltage
Detect Delay
Integer In number of lines cycles
10
SCR2 Overvoltage
Setpoint
Integer In % of nominal above nominal
11
SCR2 Overvoltage Detect
Delay
Integer In 1/4 lines cycles
12
SCR2 I peak Transfer
Setpoint
Integer x 10
13
Max. Transfer Phase
Angle
Integer In degrees
14
Output Frequency
Deviation
Integer Freq. in Hz x 10
15 ReTransfer Delay Time Integer In seconds
16 Horn Volume Integer Range: 1-10
17 Critical Option Enabling Bitpacked See section 12.1.3.
18
Non-Critical Option
Enabling
Bitpacked See section 12.1.3.
Group 4:
Event Mask
Settings
1 to
63
Event Mask settings for
faults
Event Mask See section 12.1.4.
64 to
143
Event Mask settings for
alarms
Event Mask See section 12.1.4.
Table 11 Group settings and values (continued)
Group Item: Description Value Type Value Notes
