Communication Interfaces
82
Critical Option Enabling
bit0—EnableManual_IPeakReset
bit1—EnableAutoRestart
bit2 through bit15 - not used (set to 0)
Non-Critical Option Enabling
bit0 — EnableAutoReXfer
bit1 through bit15 — not used (set to 0)
The bits are set in reverse order, from bit 15 on the left to bit 0 (zero) on the right. The bits are
grouped in four sets of four bits each, as such:
0000 0000 0000 0000
|................................|
bit 15.........................bit 0
Since each bit represents a setting, a bit can be enabled or disabled:
• 1 = installed option or enabled feature
– or –
• 0 = option not installed or feature not enabled
Enabling or disabling the bits in each group creates a binary value for that group. For example, if the
fourth bit in a group is set to 1, the group group’s binary value is 0001.
Each group is translated into a hexadecimal equivalent. The group with the value of 0001 has a hex
equivalent of 1.
You can use this table to help with the conversion:
The hex value for each group is entered in the command as four digits.
To summarize the procedure:
1. Set each bit position.
2. Convert the binary value each group into its hex equivalent.
3. Enter the hex values for each group, in order, into the command for the value parameter.
The following example explains how the conversion is completed.
Table 12 Binary-hexadecimal conversions
Binary value
Hex
Equivalent Binary value
Hex
Equivalent
0000 0 A 1010
0001 1 B 1011
0010 2 C 1100
0011 3 D 1101
0100 4 E 1110
0101 5 F 1111
0110 6
0111 7
1000 8
1001 9
