1. OPERATION
1-13
1.5.4 Setting up graphic displays
1. Select GRAPHIC referring to paragraph 1.5.1.
2. Press the [ENT] key to show the graphic display options window.
SPDMETER1
SPD(SOG)
TEMP
COMPASS
ROT
SPDMETER2
SPD(STW)
WIND
CURRENT
RAI
Graphic display options window
3. Select graphic display desired and then press the [ENT] key. For water
temperature, speedometer1 or speedometer2 one of the following displays
appears; go to step 4. For wind, compass, current or RAI no further operation
is necessary; press the [MENU] key twice to close the menu. For ROT,
choose ROT max. range among 30°, 60°, 90°/min.
Speedometer setup menu
GRAPHIC
START FROM: + 0
INTERVAL : 10
< SPEEDOMETER SETUP >
010203040
Water temperature meter setup menu
GRAPHIC
START FROM: + 0
INTERVAL : 10
< TEMPMETER SETUP >
010203040
Start point
Interval
Start point
Interval
GRAPHIC
MAX. RANGE: 30 /MIN 0
< ROT DISPLAY SETUP >
ROT display setup menu
Speedometer and water temperature graphic menus
4. Press the [ENT] key.
5. Use ◄ or ► to select location and ▲ or ▼ to enter value and switch from
plus to minus and vice versa. The setting range is -99 to +99.
6. Press the [ENT] key, and the cursor shifts to INTERVAL.
7. Press the [ENT] key.
8. Enter scale interval: Use ◄ or ► to select location and ▲ or ▼ to enter value.
The setting range is 1 to 99.
9. Press the [ENT] key.
10. Press the [MENU] key twice to close the menu.
Note: The settings of START FROM and INTERVAL on the SPEEDOMETER
and TEMPMETER SETUP are linked. Therefore they can not be set
individually.
