1. OPERATION
1-14
1.6 Displaying Rx Data
Data currently being received can be shown by using the [*] key. Below is a
sample Rx data display.
POSN 37°59.882'N
122°50.952'W
TIME 01-FEB-04
00:05:37
SOG 12.6 KT
STW 12.8 KT
COG 56.0°*1
ROT 42°/MIN
HDG 65.0°*1
TEMP 62.37°F
DEPTH 123.5 FT
WIND 65.0° (T)*2
8.1KT
WPT 200.0°*1
41.5NM
XTE 0.71NM
CURENT 7.07KT
64.0°*1
TD 32145.1
12245.2
PRESSURE 1024.5hPa
AIR TEMP 77.0°F
HUMIDITY 86.2% (T)*2
[*] Key
[*] Key
[*] Key
ODOMETER 4.33NM
TRIPMETER 2.88NM
RSA 49.5°S
ETA 01-FEB-04
10:04:06
1/4
2/4
3/4
4/4
[*] Key
*
1 = True bearing shown as "
°
";
magnetic bearing as "
°
M".
*2 = True direction shown as "T";
apparent direction shown as "A".
Rx data display
