Menu item Sub-menu item Sub-menu item Values and Description
Ping Test This test is used to check network communications.
This test sends link-level packets to a remote network
host, then waits for an appropriate response. To run a
ping test, set the following items:
Dest Type Specify whether the target device is an IPv4 or IPv6
node.
Dest IP IPV4: Type the IPv4 address.
IPV6: Type the IPv6 address.
Packet Size Specify the size of each packet, in bytes, to be sent to
the remote host. The minimum is 64 (default) and the
maximum is 2048.
Timeout Specify the length of time, in seconds, to wait for a
response from the remote host. The default is 1 and
the maximum is 100.
Count Specify the number of ping test packets to send for this
test. Select a value from 1 to 100. To configure the test
to run continuously, select 0.
Show Results If the ping test was not set for continuous operation,
you can choose to display the test results. Select Yes
to show results. If you select No (default), results are
not shown.
Execute Specify whether to initiate the ping test. Select Yes to
initiate the test, or No to not run the test.
Table 2-3 Jetdirect sub-menus (continued)
ENWW Initial Setup menu 25
