Identifies the original image’s paper size.
Sets the width and color for the eight plotter pens. A width and a color
option are available for each pen.
» Note:
See chapter 5, “Additional Technical Information,” for more
information on the HP-GL emulation color encoding equation.
Menu Administration/Emulations/HPGL/Paper Type
Choices A (letter/8.5”x11.0”), A3 (297x420 mm), A4 (210x297 mm), B
(11.0”x17.0”), Scale to Paper
Default Scale to Paper
Menu Administration/Emulations/HPGL/Pen
x
/Width
Choices 00-60 (0.1-6.0 mm)–see Notes below
Default Pen 1—7 (0.7 mm)
Pen 2—3 (0.3 mm)
Pen 3—3 (0.3 mm)
Pen 4—3 (0.3 mm)
Pen 5—3 (0.3 mm)
Pen 6—3 (0.3 mm)
Pen 7—3 (0.3 mm)
Pen 8—3 (0.3 mm)
Notes A pen width of 00 defaults to 0.1 mm.
