PLAYBACK (cont.)
6
q
PLAY
NTSC Playback
Your video recorder is equipped with NTSC circuitry that can
play back NTSC tapes.
LOAD A CASSETTE
1
Insert a cassette recorded in NTSC.
START PLAYBACK
2
Press PLAY. “NT” appears on the display panel.
● Some TVs shrink the picture vertically and place
black bars at the top and bottom of the screen. This is
not a malfunction on the part of either the video
recorder or the TV.
● The picture may roll up and down. This can be
corrected using the V-HOLD control found on some
TVs. (This cannot be corrected if the TV does not
have a V-HOLD control.)
● The counter and tape remaining time readings will be
incorrect.
● During search, still, or frame-by-frame playback, the
picture will be distorted, and there may be a loss of
colour.
● Depending on the type of TV, the top and bottom
portions of superimposed displays may be cut off
during NTSC playback.
12
45
3
6
8
0
7
9
2
AUDIO MONITOR
PLAY
Soundtrack Selection
Your video recorder is capable of recording three soundtracks (HI-FI L, HI-FI R and NORM) and will play back the one you select.
During Playback
Pressing AUDIO MONITOR on the remote control changes the soundtrack being played back as follows:
TRACK
Recorder's Front Panel On-Screen Display
USE
L + R HI FI For Hi-Fi stereo tapes
L HI FI For main audio of Bilingual tapes
R HI FI For sub audio of Bilingual tapes
NORM NORM For audio-dubbed tapes
L + R + NORM HI FI For audio-dubbed tapes
NORM
NOTES:
●
"L + R" should normally be selected. In this mode, Hi-Fi stereo tapes are played back in stereo, and the NORM track is played back
automatically for tapes with only normal audio.
●
For instructions on recording NICAM stereo and bilingual programmes, refer to page 24.
●
Bilingual programmes are not currently broadcast in the U.K.
●
"ON SCREEN" must be set to "ON" or the on-screen displays will not appear (
੬
pg. 23).
