23
On-Screen
Displays
You can choose whether or not to have various operational
indicators appear on screen, by setting this function ON or OFF.
TURN ON THE RECORDER
1
Press OPERATE.
ACCESS MODE SELECT
SCREEN
2
Press MODE. The On-
Screen/B.E.S.T. screen
appears.
SELECT MODE
3
The pointer should already be next to “ON SCREEN”. If
not, press PUSH JOG%
to place it there.
ENABLE/DISABLE
ON-SCREEN DISPLAY
4
The default setting is “ON”, so if you want on-screen
displays, leave the setting as is and go to step 5. If you
don’t want the displays to appear, press PUSH JOG
to set “ON SCREEN” to “OFF”.
CLOSE MODE SELECT
SCREEN
5
Press MODE.
6
q
12
45
3
6
8
0
7
9
2
1
3
The superimposed indication on the TV screen tells you what the recorder is doing.
1– Operation mode indicators
2– Preset position number and station name/Aux. indicator
(AUX1, AUX2 or F-AUX)
3– Cassette loaded mark
4– Tape speed SP/LP/EP (EP is for NTSC playback only)
5– Clock display
6– Current day/month/year
7– NICAM display
8– Tape direction
9– Tape position indicator ( pg. 15)
10– Counter display (including Counter Memory indicator)
11– Audio mode display
12– Tape remaining time indicator
13– Timer warning display
MODE
OPERATE
q6
PR. 12 ABCD ] SP
23 : 59
31. 12. 96 – WARNING–
TIMER RECORDING
TO START SOON
[CANCEL]
ST NICAM
HI FI M –9 : 59 : 59
NORM REMAIN 9 : 59
4
3
8
10
12
2
5
6
13
1
OPERATE
ON SCREEN : ON
B.E.S.T. : ON
[5
]: SELECT
[ ]: ON/OFF
[MODE] : EXIT
%
5
PUSH JOG
7
0
++
+
+
9
11
