30
Confi guring the WT-1
Before adjusting network settings as shown below,
select Off in the Wireless LAN > Transceiver menu.
OK
Transceiver
Wireless LAN
SET UP
Off
On
OFF
ON
Wireless
SSID
1
D2H
Communication mode Infrastructure
Channel —
Encryption Disabled
1
Same SS-ID must be assigned to wireless LAN adapter.
TCP/IP
IP address
1
Obtain IP address automatically: Off
IP address: 192.168.1.2
Subnet mask: 255.255.255.000
DNS Disabled
Gateway Disabled
1
In this example, it is assumed that network uses class C private IP addresses and sub-
net masks. Be sure that IP address is not same as that assigned to ftp server or wireless
LAN adapter. For example, if ftp server is 192.168.1.3, wireless LAN adapter can be
assigned 192.168.1.1, and WT-1 can be assigned 192.168.1.2. All addresses must be
in same class.
