104 Maintenance Releases
If the firmware is out of date, the system flashes the firmware.
5
When the upgrade completes, remove the CD from the CD-ROM
drive.
6 Use the ASM Remote Control to restart the server and boot to
the operating system:
Server > Tasks > Server Restart
--End--
Installing diagnostics firmware upgrades
Use this procedure to upgrade the diagnostics firmware. This procedure
requires the reboot of the server.
Prerequisites
•
You must be assigned to the SSA role (ntsysadm).
• You must have the CD containing the diagnostics firmware upgrade
file.
Procedure Steps
Step Action
1
Load the diagnostics firmware upgrade CD into the CD-ROM
drive.
2
Log on to the server as the SSA role (ntsysadm).
3 Reboot the server.
sudo reboot
4 If the operating system has been installed, change the boot
sequence so that the CD-ROM is the primary boot device by
doing the following:
• When the BIOS information appears, press F12 to select the
boot sequence.
• Select CD-ROM as the primary boot device.
Otherwise, wait for the server to reboot.
The IBM Flash Update Utility automatically flashes the firmware
and reboots the system when it completes.
Attention: It may take up to 5 minutes for the firmware to be
flashed. Do not power off or restart system.
Application Server 5300
Nortel AS 5300 Installation
NN42040-300 01.04
4 November 2008
Copyright © 2007-2008 Nortel Networks
.
