Specifications
Safety regulations
UL1950
cUL (CSA No. 950)
FCC Class A
IC Class A
NEMKO (EN60950)
CE (LVD, EMC)
C-Tick
General
Dimensions 325 × 110 × 285 mm (12
7
/8 × 4
3
/8
× 11
1
/4 inches) (w/h/d)
(without the projection parts)
Mass Approx. 4.9 kg (10 lb 13 oz)
Power requirements
AC 100 to 240 V, 2.9–1.2 A,
50/60 Hz
Power consumption
Max. 290 W
(Standby mode: 4.7 W)
Heat dissipation 989.6 BTU
Operating temperature
0 °C to 35 °C (32 °F to 95 °F)
Operating humidity
35 % to 85 % (no condensation)
Storage temperature
–20 °C to 60 °C (–4 °F to 140 °F)
Storage humidity 10 % to 90 %
Supplied accessories
Remote Commander (1)
R6 (Size AA) batteries (2)
HD D-sub 15-pin cable (2 m) (1)
(1-791-992-31)
USB cable A type – B type (1)
(1-790-081-31)
CD-ROM (Application software)
(1)
AC power cord (1)
Air filter (for replacement) (1)
Lens cap (1)
Operating Instructions (1)
Installation Manual for Dealers (1)
Quick Guide (1)
Design and specifications are subject to change
without notice.
SYNC/HD: Composite sync
input: 1-5 Vp-p high impedance,
positive/negative
Horizontal sync input: 1-5 Vp-p
high impedance, positive/
negative
VD: Vertical sync input: 1-5
Vp-p high impedance, positive/
negative
AUDIO: Stereo minijack
500 mVrms, impedance more
than 47 kilohms
INPUT B INPUT B: HD D-sub 15-pin
(female)
Analog RGB:
R: 0.7 Vp-p ±2 dB
(75 ohms terminated)
G: 0.7 Vp-p ±2 dB
(75 ohms terminated)
G with sync: 1 Vp-p ±2 dB sync
negative
(75 ohms terminated)
B: 0.7 Vp-p ±2 dB
(75 ohms terminated)
SYNC/HD: Composite sync
input: 1-5 Vp-p high impedance,
positive/negative
Horizontal sync input: 1-5 Vp-p
high impedance,
positive/negative
VD: Vertical sync input:
1-5 Vp-p high impedance,
positive/negative
AUDIO: Stereo minijack
500 mVrms, impedance more
than 47 kilohms
OUTPUT MONITOR: HD D-sub 15-pin
(female)
Analog RGB/Component:
R/R-Y, G/Y, B/B-Y: Gain Unity,
75 ohms
SYNC/HD, VD: 4 Vp-p (open),
1 Vp-p (75 ohms)
AUDIO (variable out): Stereo
minijack, max. 1 Vrms, When an
output signal is 500 mVrms,
impedance less than 5 kilohms
REMOTE RS-232C: D-sub 9-pin (female)
