D14637.01—MARCH 2010
26
TANDBERG Quick Set C20/C20 Plus and Profiles using C20
Administrator guide
Contents Introduction Advanced configuration Password protection About monitors Appendices Contact us
www.tandberg.com
The Video settings, cont... The Video settings, cont...
Video Input Source 1 Connector
Select which video input connector to be active on connector group 1.
Valuespace: <HDMI>
HDMI: Select HDMI when you want to use the HDMI connector as input
Example: Video Input Source 1 Connector: HDMI
Video Input Source 2 Connector
Select which video input connector to be active on connector group 2.
Valuespace: <DVI>
DVI: Select DVI when you want to use the DVI-I connector as input.
Example: Video Input Source 2 Connector: DVI
Video Input Source [1..2] Name
Customizable name of the connector group. Enter the name of the video input source 1-3.
Valuespace: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: Video Input Source 1 Name: “”
Video Input Source [1..2] OptimalDefinition Profile
The system will automatically choose what resolution and framerate to transmit based on input resolution/
framerate, available bandwidth and wether ths source is configured for motion or sharpness. For motion
sources, this setting can be used to adjust how rapidly the system should increase the transmitted
resolution when increasing bandwidth. For instance, if the source is a camera input is 1920x1080p60, the
system will transmit 1920x720p60 at about 2.2Mb/sec and above with this setting set to normal, but will
will transmit 1920x720p60 at about 1.1Mb/sec and above with this setting set to high. In general you could
choose medium or high if you have good quality video inputs and good lighting conditions, while normal
would give a good experience in most conditions, including not optimal lighting.
Valuespace: <Normal/Medium/High>
See Table 1: Optimal definition for systems supporting 1080p and Table 2: Optimal definition for
systems supporting 720p60.
Example: Video Input Source 1 OptimalDenition Prole: Normal
Table 1: Optimal definition, for systems supporting 1080p
w288p30 w448p30 w576p30 720p30 1080p30
Normal 256kbit/s 512 kbit/s 768 kbit/s 1152 kbit/s 2560 kbit/s
Medium 128kbit/s 384 kbit/s 512 kbit/s 768 kbit/s 1920 kbit/s
High 128kbit/s 256 kbit/s 512 kbit/s 768 kbit/s 1472 kbit/s
Table 2: Optimal definition, for systems supporting 720p60
w144p60 w288p60 w448p60 w576p60 720p60
Normal 128kbit/s 512 kbit/s 1152 kbit/s 1472 kbit/s 2240 kbit/s
Medium 128kbit/s 384 kbit/s 768 kbit/s 1152 kbit/s 1472 kbit/s
High 128kbit/s 256 kbit/s 512 kbit/s 768 kbit/s 1152 kbit/s
