Integrated Fast Setup
59
If Full setup is selected, the parameters in the interface cards revert to
their default values.
Setting Special Parameters
If one or more individual interface cards requires one of the special
situations referred to in the previous section or needs to remain
unaltered, you need to do one of the following:
■
Use the Switch setup mode of the Integrated Fast Setup to set up the
CoreBuilder 7000 family ATM switch only and then use the Fast Setup
of each installed interface card separately.
■
Use the Full setup mode of the Integrated Fast Setup to configure the
CoreBuilder 7000 family ATM switch and all installed interface cards
and then use the Fast Setup for the particular interface card in order to
restore its special parameter values.
Setup Procedure
Sections
The Integrated Fast Setup procedure contains the following sections:
Table 14
Setup Procedure Sections
Setup Section Description
1
Routing Mode
Set the Routing Protocol to be used
2
Network Prefix
Set Network Prefix for CoreBuilder 7000
3
PNNI Parameter
Set the PNNI node level (for the PNNI protocol —
Version 4.5 extended only)
4
LE Parameters
Set LE Parameters for CoreBuilder 7000 (LECS
and LES states)
5
LECS Address
Set resident active LECS address for CoreBuilder
7000
6
FastBUS Configuration
Configure the FastBUS card if installed.
7
Interface Type
Set the interface type port parameters for
CoreBuilder 7000
8
LE Client Configuration
Define potential VLANs by assigning names to
ELANs. Exit this section by pressing Enter only.
9
Virtual Network
Configuration
Assign chassis ports to potential VLANs.
10
Admin VN Management
Configuration
Set up admin VLAN in all modules including
setting IP address
11
Confirmation
Confirm setup
