122
Agilent E1439 Programmer's Reference
Functions listed alphabetically
Return Value
AGE1439_SUCCESS indicates that a function was successful.
Values other than AGE1439_SUCCESS indicate an error condition or other important status
condition. To determine the error message, pass the return value to “age1439_error_message” on
page 102.
See Also
“Commands which halt active measurements” on page 198, “Default values” on page 201,
“age1439_init” on page 132, “age1439_input_setup” on page 141, “age1439_clock_setup” on
page 78, “age1439_frequency_setup” on page 128, “age1439_filter_sync” on page 123,
“age1439_data_setup” on page 90, “Frequency and filtering” in chapter 3
Signal Bandwidth
MHz
Sample Rate
Msamples
sigBw .25 dB 15 dB Decimate OFF Decimate ON
1 ±18 ±25 N/A 50
2 ±9 ±12.5 50 25
3 ±4.5 ±6.25 25 12.5
4 ±2.25 ±3.125 12.5 6.5
>4 Continue to decimate by factors of two
