AT-2716POE Fast Ethernet Fiber & PoE Adapter Installation and User’s Guide
25
7. Depending upon model order connect an appropriate unused power
connector from the system power supply harness to the AT-2716POE
SATA or IDE power connector receptacle as shown in Figure 7.
Figure 7. Installing System PS SATA Harness connector to AT-
2716POE
8. Replace the system’s cover and secure it with the screws removed in
Step 2.
9. Disconnect any personal antistatic devices.
10. Power the system on.
Note
Once the system returns to proper operation, the adapter
hardware is fully installed, but is not fully functional until the AT-
2716POE driver software (Chapters 3 and 4) and AT-2716POE
AT-Mux Configuration software (Chapter 5) is installed.
Next, connect the network cables. See “Connecting the Network Cables”
on page 26.
