IntraCore IC3624PWR Layer 2 PoE Switch with Dual Gigabit
The following table describes the areas you see from the General Information screen.
Heading Description
System up Time System run time after boot up
Boot Code Version Date The version and timestamp of boot code
Runtime Code Version Date The version and timestamp of runtime code
Hardware Information
Version
DRAM Size
Fixed Baud Rate
Flash Size
Hardware associated information
Hardware revision version
Size of DRAM on system
Data rate on console port, set to 19200
Size of Flash memory
Administration Information
System Name
System Location
System Contact
Name of system (user defined)
Location of system (user defined)
Contact information (user defined)
System Address Information
MAC Address
IP Address
Subnet Mask
Default Gateway
DHCP Mode
MAC Address of system
Default IP address (user defined)
Default Subnet mask (user defined)
Default gateway (user defined)
Enabled/Disabled DHCP function
6.2 Basic Configuration Menu
The Basic Configuration screen allows you to configure several basic system-related settings for future use. You
reach this screen from the Main Menu.
There are eight submenus at Basic Configuration Menu.
Administration Configuration
IP Configuration
SNMP Configuration
Port Configuration
System Security
Forwarding DB
SNTP Configuration
ARP Table
Quit to previous menu
