8-6
Random Access Adjustment Mode
5975967 BARCOGRAPHICS 9200 030798
Select with or
then <ENTER>
<EXIT> to return.
Select with or
then <ENTER>
<EXIT> to return.
Select with or
then <ENTER>
<EXIT> to return.
Delete
To delete a selected file out of the list of files.
Use the control disc to select DELETE and press ENTER. The delete
selection menu will be displayed.
Push the control disc up or down to select a file and press ENTER.
If [All] is selected, your password has to be entered before all files
will be deleted.
A confirmation menu "Delete file 'file name'?" is displayed. When you
want to delete the file, press ENTER. If you do not want to delete the
file, press EXIT.
Note : the active file cannot be deleted.
FILE SERVICE
LOAD
EDIT
RENAME
COPY
DELETE
OPTIONS
DELETE FILE
Filename Src Resolution
-----------------------------------------------------
ntsc .s01 1 675x240i
ntsc .c01 1 675x240i
ntsc_2 .s01 1 675x240i
-----------------------------------------------------
Active file : ntsc.c50
Select with or
<ENTER> to accept
<EXIT> to return.
CONFIRM
DELETE FILE
Delete file:
ntsc.c01?
<ENTER> to confirm
<EXIT> to return
File Options
Use the control disc to select OPTIONS and press ENTER. The option
selection menu will be displayed.
Press ENTER to toggle between [name] and [index]
[name] : The files in the file list will be sorted on the file name.
[index] : The files in the file list will be sorted on the file extension.
FILE SERVICE
LOAD
EDIT
RENAME
COPY
DELETE
OPTIONS
FILE OPTIONS
FILE SORT [NAME]
Select with or
then <ENTER>
<EXIT> to return.
Picture Tuning
Highlight Picture Tuning by pushing the control disc up or down and
press ENTER to select.
The Picture Tuning menu will be displayed.
The next items are available :
- sync slow/fast
- still video
- color balance
- gamma
RANDOM ACCESS
ADJUSTMENT MODE
FILE SERVICE
PICTURE TUNING
GEOMETRY
PICTURE TUNING
SYNC [SLOW]
STILL VIDEO [ON]
COLOR BALANCE
GAMMA
Select with or
then <ENTER>
<EXIT> to return.
