Service Mode
11-2 5975947 BARCOGRAPHICS 9200 120297
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJ. ADDRESS
CHANGE BAUDRATE PC
RESET LAMP RUNTIME
LAMP RUNTINE HISTORY
LAMP POWER : 1500W
MORE...
Select with or
then <ENTER>
<EXIT> to return.
SERVICE
PANEL ADJUSTMENTS
PRESET INPUT BALANCE
60Hz TRACKING
I2C DIAGNOSIS
MORE...
Select with or
then <ENTER>
<EXIT> to return.
PANEL ADJUSTMENT
RED COARSE
FIELD FLICKER
BLACK LEVEL TOP
BLACK LEVEL BOTTOM
GAIN TOP
GAIN BOTTOM
Change color+pattern
with or
Select with or
then <ENTER>
<EXIT> to return.
PRESET INPUT BALANCE
WHITE BALANCE
Select with <ENTER>
<EXIT> to return
Adjust
red with or
blue with or
60 Hz TRACKING
-15 +150
I2C DIAGNOSIS
DCA
LCD DRIVER SC76013 E6H ###
LCD DRIVER SC76013 E8H ###
LCD DRIVER SC76013 EAH###
LCD DRIVER TDA8444 48H ###
INPUT SELECTOR
PCF8574A 46H # ##
INPUT SELECTOR
PCF8574A 7EH # ##
DECODER PCF8574 4EH ###
DECODER SAA7151B8AH ###
DECODER SAA7152 B2H ###
DECODER SAA7192AE0H ###
LAMP DRIVER PCF8574A 72H ###
POWER SUPPLY 87C752 10H # # #
Select with or
then <ENTER>
<EXIT> to return.
SERVICE
IDENTIFICATION
CHANGE PASSWORD
CHANGE LANGUAGE
CHANGE PROJ. ADDRESS
CHANGE BAUDRATE PC
RESET LAMP RUNTIME
LAMP RUNTINE HISTORY
LAMP POWER : 1500W
MORE...
Identification
To display the Identification screen, push the control stick forward
or backward to highlight Identification and press ENTER to display
the Identification screen.
The Identification screen gives an overview of :
- type of projector
- projector address
- software version
- installation configuration
- baud rate
- text ON
- projector serial number
- projector run time
- software version
- Proj. Address : to change the address of the projector, see Change
Projector Address in this chapter.
- Installation : possible installations :
* Front/Ceiling
* Front/Table
* Rear/Ceiling
* Rear/Table
To change the installation configuration follow the instructions in
chapter Installation Set Up.
- Baud rate : transfer speed for communication with a IBM PC (or
compatible) or MAC. The baud rate of the projector must be the same
as the baud rate of the connected computer. When there is a
difference, consult 'Change Baudrate PC' in this chapter.
- Projector Run Time : gives the total run time since the first start up.
All projectors leave the factory with a run time of approximately 24
hours.
- Projector Serial number : indicates the fabrication number of the
projector. This number can be useful when calling for technical
assistance.
- type of projector : BARCOGRAPHICS 9200
