CBM-253 User’s Manual
98
CITIZEN
GS / m
[Name] Printing of the downloading/bit image
[Code] <1D>H <2F>H <m>
[Defined range] 0 ≤ m ≤ 3
[Function] Prints the downloading/bit image using the mode specified by m. The modes specified by
m are shown in the following table.
m Mode name
Dot density in the
vertical direction
Dot density in the
horizontal direction
0 Normal mode 203DPI 203DPI
1 Double wide mode 203DPI 101DPI
2 Double height mode 101DPI 203DPI
3
Double wide and
Double height mode
101DPI 101DPI
[Items requiring caution]
If there is data present in the print buffer, this command will be disregarded.
If the downloading/bit image has not been defined, this command will be disregarded.
Parts of the downloading/bit image that exceed the 1 line length will not be printed.
It will not be possible to define downloading characters and downloading/bit images at
the same time.
[Initial value] Not defined
[Reference] GS *
[Program example] [Printing result]
Refer to the program example and the printing result for GS * on page 97.
