CBM-253 User’s Manual
34
CITIZEN
2 DSW2 (Only mounted in serial interface printers)
DSW1 ON OFF
1 Xon/Xoff control DTR/DSR control
2 Parity enabled No parity
3 Even parity Odd parity
4 7 bits 8 bits
5
6
Baud rate
(Refer to the table below.)
7
Data rejected during
a receiving error
'?' character printed
during a receiving error
8 Spare
Baud rate
DSW2-5 DSW2-6 Baud rate
ON ON 1200
OFF ON 4800
ON OFF 9600
OFF OFF 19200
Note 2 : The dip switch setting only become valid at the time when the power is switched on. According, if the
setting are changed when the power is on, the switching will not be effe ctive.
