BIOS Setup
CPU Clock Setting
This field provides several options for selecting the external system
bus clock of the processor. The available options allow you to adjust
the processor’s bus clock by 1MHz increment.
Important:
Selecting an external bus clock other than the default setting
may result to the processor’s or system’s instability and are not
guaranteed to provide better system performance.
O. C. Failed Control
If after overclocking, the system failed to function properly, the sys-
tem will automatically adjust the CPU clock according to the value
selected in this field. The adjusted clock speed is the actual CPU
clock minus the value selected in this field.
Current DRAM Speed
This field will show the detected speed of the DRAM.
PCIE Clock Sync With
CPU Clock PCI Express clock is synchronous with CPU FSB
clock.
O.C. Mode Active PCI Express clock.
Fix 100MHz PCI Express clock is fixed at 100MHz.
PCIE Clock Setting
This field is used to select the PCI Express clock. The options are
available in 1MHz increment.
PCI Clock Setting
This field is used to select the PCI clock.
